Каталог запасных частей к технике: DYNAPAC Dynapac CA1500. Control

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
8
8
9
9
9
10
11
11
12
16
17
18
19
20
20
22
23
25
26
30
31
36
36
37
38
39
40
41
42
42
42
43
44
45
46
47
48
49
50
Позиция на иллюстрации Заводской номер детали Название детали
1 Portplate Port plate
2 Positioningpiston Positioning piston
3 Positioningtrunnion Positioning trunnion
4 Controlbush Control bush
5 Controlpiston Control piston
6 Pressurespring Pressure spring
7 Lockingscrew Locking screw
8 Throttlescrew Throttle screw
9 Throttlescrew Throttle screw
10 Valvepin Valve pin
11 Throttlepin Throttle pin
12 Lockingscrew Locking screw
16 Socketheadscrew Socket head screw
17 Socketheadscrew Socket head screw
18 Cylinderpin Cylinder pin
19 Lockingscrew Locking screw
20 Lockingscrew Locking screw
22 4812157169 O-ring
23 4812157170 O-ring
25 Doublebreak Double break-off plug
26 4812158756 O-ring
30 Needleroller Needle roller
31 4812036305 Solenoid valve
36 4812158757 Flush and boost pressure valve
37 Flushingvalvehousing Flushing valve housing
38 Flushingpiston Flushing piston
39 Valvepiston Valve piston
40 Lockingscrew Locking screw
41 Lockingscrew Locking screw
42 Washer Washer
43 Pressurespring Pressure spring
44 Pressurespring Pressure spring
45 Socketheadscrew Socket head screw
46 4812157460 O-ring
47 4812157170 O-ring
48 Retainingring Retaining ring
49 Shim Shim
50 Orifice Orifice
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
