Каталог запасных частей к технике: DYNAPAC Dynapac CA1500. Control

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
Позиция на иллюстрации Заводской номер детали Название детали
1 Controlpart Control part
2 Controlhousing Control housing
3 Controlbush Control bush
4 Controlpiston Control piston
5 Adjustingbushing Adjusting bushing
6 Springcollar Spring collar
7 Springcollar Spring collar
8 Pressurespring Pressure spring
9 Pressurespring Pressure spring
10 Pressurespring Pressure spring
11 4812158081 O-ring
12 Socketheadscrew Socket head screw
13 Lockingscrew Locking screw
14 Retainingring Retaining ring
15 Threadedpin Threaded pin
16 Cylinderpin Cylinder pin
17 Sealingnut Sealing nut
18 Doublebreak Double break-off plug
19 4812158759 Proportional solenoid
20 Flushandboostpressurevalve Flush and boost pressure valve
21 Valvehousing Valve housing
22 Flushingpiston Flushing piston
23 Valvepiston Valve piston
24 Lockingscrew Locking screw
25 Lockingscrew Locking screw
26 Washer Washer
27 Pressurespring Pressure spring
28 Pressurespring Pressure spring
29 Socketheadscrew Socket head screw
30 4812157460 O-ring
31 4812157170 O-ring
32 4812158082 O-ring
33 Retainingring Retaining ring
34 Lockingscrew Locking screw
35 Shim Shim
36 4812158760 Orifice
37 Portplate Port plate
38 Positioningpiston Positioning piston
39 Positioningtrunnion Positioning trunnion
40 Pistonwithpistonrings Piston with piston rings
41 Threadedpin Threaded pin
42 4812158079 Check valve
43 Bush Bush
44 Socketheadscrew Socket head screw
45 4812158080 O-ring
46 Socketheadscrew Socket head screw
47 Cylinderpin Cylinder pin
48 Doublebreak Double break-off plug
