Каталог запасных частей к технике: DYNAPAC Dynapac CA1500. 4812116230 Hydraulic motor

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
7
8
8
9
10
11
12
13
14
14
15
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
43
44
45
46
46
47
Позиция на иллюстрации Заводской номер детали Название детали
1 Endcap End cap
2 Screw Screw
3 4700909344 Needle roller bearing
4 Pin Pin
5 Plug Plug connector see engine Gr. 9
6 O-ring O-ring
7 Spring Spring
8 O-ring O-ring
9 Spool Spool
10 Plug Plug connector see engine Gr. 9
11 O-ring O-ring
12 Spring Spring
13 Poppet Poppet
14 Plug Plug connector see engine Gr. 9
15 O-ring O-ring
16 Cylinderblockkit Cylinder block kit
17 Retainingring Retaining ring
18 Springretainer Spring retainer
19 Spring Spring
20 Washer Washer
21 Slipperholddownpin Slipper hold down pin
22 Slipperretainerguide Slipper retainer guide
23 Slipperretainer Slipper retainer
24 Pistonassy Piston assy
25 4812158596 Valve plate
26 Servopistonassy Servo piston assy
27 4700936556 Seal ring
28 4700936555 O-ring
29 Spring Spring
30 Swashplate Swashplate
31 4812158597 Gasket
32 Pin Pin
33 Retainingring Retaining ring
34 Housing Housing
35 Swashplatebearingkit Swashplate bearing kit
36 Plug Plug connector see engine Gr. 9
37 4812158653 O-ring
38 Plug Plug connector see engine Gr. 9
39 4700813617 O-ring
40 4812158599 Shaft
41 4812158655 Ball bearing
42 4700901727 Snap ring
43 Retainingring Retaining ring
44 4700937061 Lip seal
45 Sealsupportwasher Seal support washer
46 Pin Pin
47 4812158656 Seal kit
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
