Каталог запасных частей к технике: DYNAPAC CP275. 4812266670 Air on the run
1
1
2
3
4
5
8
9
10
11
12
13
14
15
16
17
17
17
18
19
20
21
22
23
24
25
26
27
28
31
32
33
34
35
36
37
38
39
40
40
40
41
42
43
44
48
49
50
51
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4812268053 | T-junction | |
| 2 | 4812268117 | Bracket | |
| 3 | 4812268051 | Air tank | |
| 4 | 4812268061 | Joint | |
| 5 | 4812268062 | Adjustable adapter | |
| 6 | 4812266665 | Valve | |
| 7 | 4812268067 | Joint | |
| 8 | 4812268066 | Joint | |
| 9 | 4812268065 | Solenoid valve | |
| 10 | 4812268050 | Joint | |
| 11 | 4812268071 | Muffler | |
| 12 | 4812268064 | Joint | |
| 13 | 4812268052 | Joint | |
| 14 | 4700195172 | Rotor | |
| 15 | 4700257198 | Rotating nipple | |
| 16 | 4812268063 | Hose | |
| 17 | 4812268077 | Joint | |
| 18 | 4812268101 | Joint | |
| 19 | 4812266866 | Fitting | |
| 20 | 4812268104 | Joint | |
| 21 | 4812268076 | Pipe assy | |
| 22 | 4812266666 | Charge valve | |
| 23 | 4812268078 | Hose | |
| 24 | 4812268073 | Joint | |
| 25 | 4812268075 | Hose | |
| 26 | 4812268086 | Hose | |
| 27 | 4812268060 | Hose | |
| 28 | 4812268074 | Hose | |
| 31 | 4812268059 | Gas pression meter | |
| 32 | 4812268070 | Hose clamp | |
| 33 | 4812268121 | Plate | |
| 34 | 4700904229 | Washer | |
| 35 | 4700500068 | Screw | |
| 36 | 4700791182 | Nut | |
| 37 | 4812268057 | Check valve | |
| 38 | 4812268055 | Joint | |
| 39 | 4812268079 | Holder | |
| 40 | 4700500021 | Hex. screw | |
| 41 | 4812268081 | Joint | |
| 42 | 4812268087 | Blendboard | |
| 43 | 4812268084 | Handle | |
| 44 | 4812268215 | Cover assy | |
| 48 | 4700313102 | Cable ties | |
| 49 | 4812268197 | Hose | |
| 50 | 4812268198 | Hose | |
| 51 | 4812268198 | Hose |
