Каталог запасных частей к технике: DYNAPAC CP142. Propulsion system
1
2
3
4
5
6
7
8
8
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
27
28
29
30
31
32
33
34
34
35
35
36
36
37
37
38
38
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4700193773 | Connection-T | |
| 2 | 4700923384 | Split flange | |
| 3 | 4700813429 | O-ring | |
| 4 | 4700791103 | Screw | |
| 5 | 4700252285 | Hose protection | |
| 6 | 4700508067 | Screw | |
| 7 | 4700376123 | Hydraulic motor | |
| 8 | 4700900455 | Elbow | |
| 9 | 4700929226 | Flange half | |
| 10 | 4700160006 | O-ring | |
| 11 | 4700343732 | Hose clamp | |
| 12 | 4700904230 | Washer | |
| 13 | 4700500077 | Screw | |
| 14 | 4700335914 | Cover plate | |
| 15 | 4700570006 | Hex. nut | |
| 16 | 4700349933 | Flange coupling | |
| 17 | 4700904005 | O-ring | |
| 18 | 4700232222 | Plug | |
| 19 | 4700791087 | Screw | |
| 20 | 4700380168 | Accumulator | |
| 21 | 4700904640 | Washer | |
| 22 | 4700500021 | Hex. screw | |
| 23 | 4700334139 | Straight connector with O-ring | |
| 24 | 4700234810 | Connector | |
| 25 | 4700334138 | Adapter | |
| 26 | 4700234243 | T-connector | |
| 27 | 4700792135 | Elbow | |
| 28 | 4700234900 | T-connector | |
| 29 | 4700334155 | Elbow 90 | |
| 30 | 4700910162 | Measuring nipple | |
| 31 | 4700234626 | Adapter | |
| 32 | 4812100211 | Hydraulic hose | |
| 33 | 4812100211 | Hydraulic hose | |
| 34 | 4700482391 | Hydraulic hose | |
| 35 | 4700483414 | Hydraulic hose | |
| 36 | 4700483414 | Hydraulic hose | |
| 37 | 4700482182 | Hydraulic hose | |
| 38 | 4812100397 | Hydraulic hose | |
| 39 | 4700191789 | Hydraulic hose |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
