Каталог запасных частей к технике: DYNAPAC CP142. Driving lights
1
2
3
4
5
6
7
8
9
10
11
20
21
22
23
24
25
26
26
27
27
28
29
30
31
32
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4700380824 | Holder plate, Right | |
| 2 | 4700380825 | Holder plate, Left | |
| 3 | 4700791583 | Switch, driving light | |
| 4 | 4700791584 | Switch, hazard flashers | |
| 5 | 4700792413 | Switch, drive direction | |
| 6 | 4700903741 | Fuse | |
| 7 | 4700901227 | Fuse | |
| 8 | 4700904989 | Flash relay Option | |
| 9 | 4700791138 | Relay | |
| 10 | 4700904229 | Washer | |
| 11 | 4700500053 | Hex. screw | |
| 12 | 4700902066 | Headlight | |
| 13 | 4700904315 | Direction lamp | |
| 14 | 4700904316 | Direction lamp | |
| 15 | 4700904317 | Direction lamp | |
| 16 | 4700904318 | Direction lamp | |
| 17 | 4700904792 | Rubber cap | |
| 18 | 4700928502 | Bulb | |
| 19 | 4700985014 | Bulb | |
| 20 | 4700904315 | Direction lamp | |
| 21 | 4700904698 | Steel plain washer | |
| 22 | 4700533013 | Cylinder screw | |
| 23 | 4700904316 | Direction lamp | |
| 24 | 4700904317 | Direction lamp | |
| 25 | 4700904318 | Direction lamp | |
| 26 | 4700902066 | Headlight | |
| 27 | 4700902227 | Work light | |
| 28 | 4700900790 | Bulb | |
| 29 | 4700928502 | Bulb | |
| 30 | 4700985014 | Bulb | |
| 31 | 4700901369 | Bulb | |
| 32 | 4700904792 | Rubber cap |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
