Каталог запасных частей к технике: DYNAPAC CP142. Cooling system
1
2
3
4
5
6
7
8
9
10
11
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4700388922 | Expansion tank | |
| 2 | 4700903714 | Cap | |
| 3 | 4700390524 | Threaded plate | |
| 4 | 4700904229 | Washer | |
| 5 | 4700500020 | Hex. screw | |
| 6 | 4700199504 | Cooler | |
| 7 | 4812100301 | Fan guard | |
| 8 | 4700170655 | Hose | |
| 9 | 4700170656 | Hose | |
| 10 | 4700170643 | Hose | |
| 11 | 4700170644 | Hose | |
| 14 | 4700313022 | Hose clamp | |
| 15 | 4700904550 | Hose connector | |
| 16 | 4700198548 | Hose | |
| 17 | 4700198548 | Hose | |
| 18 | 4700500053 | Hex. screw | |
| 19 | 4700313075 | Hose clamp | |
| 20 | 4700904557 | Washer | |
| 21 | 4700500091 | Screw | |
| 22 | 4700313010 | Hose clamp | |
| 23 | 4700313008 | Hose clamp | |
| 24 | 4700205027 | Coolant hose | |
| 25 | 4700313035 | Hose clamp | |
| 26 | 4700234958 | Connector | |
| 27 | 4700334156 | Adapter | |
| 28 | 4700234243 | T-connector | |
| 29 | 4700234667 | Reducer | |
| 30 | 4700334135 | Tee-connector | |
| 31 | 4700334197 | Connector elbow 90 JIC | |
| 32 | 4700904229 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
