Каталог запасных частей к технике: DYNAPAC CG2300. Hydraulic drum drive and vibration rear
1
1
2
2
3
3
3
3
4
5
6
7
7
7
8
8
8
8
9
9
9
9
10
10
10
10
11
11
11
11
12
12
12
12
13
13
14
15
16
16
16
17
17
17
18
18
18
18
19
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4700792726 | Hexagon socket countersunk screw | |
| 2 | 4700395431 | Cover | |
| 3 | 4812119913 | Hydraulic hose | |
| 4 | 4700395922 | Hydraulic motor | |
| 5 | 4700390605 | Hydraulic motor | |
| 6 | 4700392523 | Gear box | |
| 7 | 4812119918 | Hydraulic hose | |
| 8 | 4812119914 | Hydraulic hose | |
| 9 | 4812119908 | Hydraulic hose | |
| 10 | 4812119908 | Hydraulic hose | |
| 11 | 4812119913 | Hydraulic hose | |
| 12 | 4812119917 | Hydraulic hose | |
| 13 | 4700395428 | Hose clamp | |
| 14 | 4700500249 | Screw | |
| 15 | 4700904229 | Washer | |
| 16 | 4812119914 | Hydraulic hose | |
| 17 | 4812119916 | Hydraulic hose | |
| 18 | 4812119908 | Hydraulic hose | |
| 19 | 4812119908 | Hydraulic hose | |
| 20 | Hydraulicblockmodule | Hydraulic block module | |
| 21 | 4700792330 | Elbow 90 orfs | |
| 22 | 4700392748 | Connector | |
| 23 | 4700791599 | Elbow 90° | |
| 24 | 4700791410 | Straight o-ring connector | |
| 25 | 4700791798 | Adapter | |
| 26 | 4700791745 | Elbow 90, O-ring with swivel | |
| 27 | 4700791536 | Straight connector | |
| 28 | 4700791536 | Straight connector | |
| 29 | 4700791410 | Straight o-ring connector | |
| 30 | 4700791599 | Elbow 90° | |
| 31 | 4700392523 | Gear box | |
| 32 | 4700904213 | Washer | |
| 33 | 4700500046 | Hex. head screw | |
| 34 | 4700500046 | Hex. head screw | |
| 35 | 4700904213 | Washer | |
| 36 | 4700500046 | Hex. head screw | |
| 37 | 4700904213 | Washer | |
| 38 | 4700791841 | Elbow 90 orfs | |
| 39 | 4700395923 | Hydraulic motor |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
