Каталог запасных частей к технике: DYNAPAC CC900S. Hydraulic propulsion and brake
1
2
2
3
4
4
5
6
6
6
7
8
9
10
11
12
13
13
14
15
16
16
17
18
19
20
20
20
21
21
22
22
23
24
24
25
25
26
26
27
27
28
28
29
29
30
30
31
32
32
33
34
35
35
36
36
37
38
39
40
40
40
41
42
42
43
44
46
46
47
48
49
50
51
51
52
53
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4700396883 | Hydraulic motor | |
| 2 | 4700791410 | Straight o-ring connector | |
| 3 | 4700791746 | Tee-connector | |
| 4 | 4700791744 | Adapter | |
| 5 | 4700396884 | Hydraulic motor | |
| 6 | 4700791743 | Straight connector orfs | |
| 7 | 4700791409 | Straight connector orfs | |
| 8 | 4812123466 | Hydraulic pump | |
| 9 | 4700904557 | Washer | |
| 10 | 4700500029 | Hex. screw | |
| 11 | 4812120635 | Measuring nipple | |
| 12 | 4700792093 | Straight connector orfs | |
| 13 | 4700791699 | Elbow 90° | |
| 14 | 4700791541 | Straight connector | |
| 15 | 4700792332 | Elbow 90 orfs | |
| 16 | 4700791745 | Elbow 90, O-ring with swivel | |
| 17 | 4812121432 | Hydraulic hose | |
| 18 | 4700387914 | Pipe | |
| 19 | 4700387915 | Pipe | |
| 20 | 4700387678 | Rubber part | |
| 21 | 4700387677 | Spacer sleeve | |
| 22 | 4700387676 | Hose bracket | |
| 23 | 4700389556 | Rubber part | |
| 24 | 4700904229 | Washer | |
| 25 | 4700500068 | Screw | |
| 26 | 4812121089 | Hydraulic hose | |
| 27 | 4700483852 | Hydraulic hose | |
| 28 | 4812123927 | Hydraulic hose | |
| 29 | 4700483689 | Hydraulic hose | |
| 30 | 4700483654 | Hydraulic hose | |
| 31 | 4700389400 | Hydraulic hose | |
| 32 | 4812123926 | Hydraulic hose | |
| 33 | 4700921056 | Clamp | |
| 34 | 4700904766 | Elbow connector | |
| 35 | 4700389409 | Hydraulic hose | |
| 36 | 4700389410 | Hydraulic hose | |
| 37 | 4700483652 | Hydraulic hose | |
| 38 | 4700500506 | Screw | |
| 39 | 4700388960 | Hose clamp | |
| 40 | 4700500505 | Screw | |
| 41 | 4700313108 | Hose clamp | |
| 42 | 4700313001 | Clamp | |
| 43 | 4700904640 | Washer | |
| 44 | 4700500019 | Hex. screw | |
| 46 | 4700904009 | O-ring | |
| 47 | 4700792170 | Adapter | |
| 48 | 4700378024 | Hose clamp | |
| 49 | 4700378025 | Hose clamp | |
| 50 | 4700283711 | Hose clamp | |
| 51 | 4700483652 | Hydraulic hose | |
| 52 | 4700904781 | Adapter | |
| 53 | 4700162005 | Washer sealing |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
