Каталог запасных частей к технике: DYNAPAC CC900S. 4812119960_Hydraulic pump To FA016536

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
25
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
42
43
43
44
45
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
83
84
85
86
87
88
89
90
91
100
Позиция на иллюстрации Заводской номер детали Название детали
4812119960 4812119960 Hydraulic pump
1 4812161052 Shaft seal kit
2 Snapring Snap ring
3 O-ring O-ring
4 Cap Cap
5 Sealring Seal ring
6 4812161053 Rotating group kit
7 Pistonshoe Piston shoe
8 Piston Piston
9 Retainerplate Retainer plate
10 Sphere Sphere
11 Pin Pin
12 Shim Shim
13 Spring Spring
14 Snapring Snap ring
15 Barrel Barrel
16 Washer Washer
17 4812161054 High pressure relief valve kit
18 O-ring O-ring
19 4812160855 Valve
20 Reliefvalve Relief valve
21 4812160999 End cover
22 Screw Screw
23 Pin Pin
25 4812161055 Bearing kit
26 Snapring Snap ring
27 Pistonguides Piston guides
28 Snapring Snap ring
29 Outerracebearing Outer race bearing
30 Innerracebearing Inner race bearing
31 Innerracebearing Inner race bearing
32 Outerracebearing Outer race bearing
33 Shim Shim
34 Sealring Seal ring
35 O-ring O-ring
36 Snapring Snap ring
37 O-ring O-ring
38 Snapring Snap ring
39 Snapring Snap ring
40 Innerracebearing Inner race bearing
41 Outerracebearing Outer race bearing
42 Bushing Bushing
43 Pin Pin
44 4812161056 Charge pump kit
45 Washer Washer
46 Gerotorkit Gerotor kit
47 O-ring O-ring
48 Pin Pin
49 Endcover End cover
50 Screw Screw
51 Snapring Snap ring
52 Sealring Seal ring
53 4812161057 Direct mechanical kit with return spring
54 Supportoflever Support of lever
55 Washer Washer
56 Screw Screw
57 Screw Screw
58 Washer Washer
59 Washer Washer
60 Washer Washer
61 Screw Screw
62 Washer Washer
63 Lever Lever
64 Pin Pin
65 Spring Spring
66 Hydrauliccontrolkit Hydraulic control kit
67 Blockslide Block slide
68 Pin Pin
69 Washer Washer
70 Screw Screw
71 4812161058 Low pressure relief valve kit
72 Screw Screw
73 Nut Nut
74 Support Engine support
75 O-ring O-ring
76 Seat Seat
77 Pin Pin
78 Spring Spring
79 Poppet Poppet
80 Plug Plug connector see engine Gr. 9
81 Housing Housing
83 4812160998 Shaft
84 Swashplate Swashplate
85 4812161051 Valve plate
86 Washer Washer
87 Screwbypasskit Screw bypass kit
88 Screwbypass Screw bypass
89 Backupring Backup ring
90 O-ring O-ring
91 Gasket Gasket
100 4812161059 Seals kit
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
