Edge cutter, front right
Edge cutter, right
Holder, edge cutter
4812120738 Hydraulic cylinder
Bearing unit
Edge cutter, left
Holder, edge cutter
Holder module
Pressing roller, module
Cutting disc module
1
1
2
2
3
3
4
4
5
5
6
7
8
9
10
11
12
13
Позиция на иллюстрации
Заводской номер детали
Название детали
1
Edgecutter,right
Edge cutter, right
2
4700792389
Elbow 45 orfs
3
4812124030
Cable harness
4
4812124029
Cable harness
5
4700791846
Adapter
6
4700921046
Clamp
7
4700356273
Spacer sleeve
8
4700500503
Screw
9
4700904735
Steel plain washer
10
Hydraulicvalvemodule
Hydraulic valve module
11
391002
Pressing roller module
12
Holdermodule
Holder module
13
Cuttingdiscmodule
Cutting disc module
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
