1
2
3
4
5
6
6
7
8
9
10
11
12
13
14
15
16
17
18
Позиция на иллюстрации
Заводской номер детали
Название детали
1
Doorassembly
Door assembly
2
4812126373
Hinge plate
3
4812122881
Hinge plate, bottom
4
4812161161
Screw
5
Sealingplug
Sealing plug
6
Washer,brass
Washer, brass
7
4812119449
Pin
8
Bushing
Bushing
9
Shimring
Shim ring
10
Hexagonnut
Hexagon nut
11
4812114598
Bolt
12
WASHER
WASHER
13
4812114603
Plate
14
4812115215
Ball stud
15
4812120272
Gasspring
16
Label-blackdot
Label - black dot
17
Sealingplug
Sealing plug
18
Sealingplug
Sealing plug
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
