4700392509
4700392509
4700392510
4700392510
4700393697
4700393697
4812124323
4812124323
4812124324
4812124324
4812124325
4812124325
4700160268
4700160268
4812124327
4812124327
1
2
2
2
2
3
4
5
6
Позиция на иллюстрации
Заводской номер детали
Название детали
4700392509
4700392509
Retainer, nozzle, strainer, yellow
4700392510
4700392510
Gasket
4700393697
4700393697
Nozzle and strainer, yellow
4812124323
4812124323
Cap, blue
4812124324
4812124324
Strainer
4812124325
4812124325
Gasket
4700160268
4700160268
O-ring
4812124327
4812124327
Nozzle
1
4700396441
Sprinkler pipe
2
4700392011
Spraying nozzle, cpl
2
4812124321
Spraying nozzle, cpl
3
4700791977
Hose connection
4
4700791975
Plastic plug threaded
5
4700792072
End plug
6
4700233215
Ball valve
