Каталог запасных частей к технике: DYNAPAC CC5200C. Hydralic system, wheels

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
7
8
9
10
11
12
13
14
16
16
17
18
18
19
19
20
20
21
21
22
22
22
22
22
22
23
23
23
24
24
24
24
25
28
29
30
31
32
33
33
33
33
34
34
34
35
36
37
38
39
40
41
42
49
50
51
52
53
Позиция на иллюстрации Заводской номер детали Название детали
1 4700500077 Screw
2 4700904570 Steel plain washer
3 4700343872 Hose clamp
4 4700335914 Cover plate
5 4700904570 Steel plain washer
6 4700570006 Hex. nut
7 4700484053 Hydraulic hose
8 4700484046 Hydraulic hose
9 4700484047 Hydraulic hose
10 Offsetcylinder Offset cylinder
11 4700484049 Hydraulic hose
12 4700484363 Hydraulic hose
13 4700484350 Hydraulic hose
14 4700484050 Hydraulic hose
16 4700484355 Hydraulic hose
17 Connectionblock Connection block
18 4700484354 Hydraulic hose
19 4700484356 Hydraulic hose
20 4700484352 Hydraulic hose
21 4700484357 Hydraulic hose
22 4700484359 Hydraulic hose
22 4700484359 Hydraulic hose
23 4700484359 Hydraulic hose
24 4700484353 Hydraulic hose
25 4700791630 T-connector ORFS
28 Gear Conveyor gear
29 Gear Conveyor gear
30 4700791536 Straight connector
31 4700791401 Elbow 90, O-ring with swivel
32 4700791414 T-connection, O-ring with swivel
33 4700484353 Hydraulic hose
34 4700484358 Hydraulic hose
35 4700791536 Straight connector
36 4700904641 Straight connector orfs
37 4700792115 Straight connector
38 4700904641 Straight connector orfs
39 4700791536 Straight connector
40 4700791401 Elbow 90, O-ring with swivel
41 4700791414 T-connection, O-ring with swivel
42 4700791798 Adapter
49 Hydraulicvalve Hydraulic valve
50 Hydraulicpumpmodule Hydraulic pump module
51 4700792115 Straight connector
52 4700904641 Straight connector orfs
53 4700791536 Straight connector
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
