Edge cutter
Edge cutter, module
4700390998 Edge cutter, cpl
4700390999 Holder
4700391009 Bearing unit
4700387275 Hydraulic cylinder
Cutting disc module
Pressing roller, module
Hydraulic valve module
Hydraulic valve
4700391018 Hydraulic valve
Disc/Roller holder
Fire extinguisher/First Aid Cushion
Fire extinguisher assembly
Asphalt temperature meter
Dyn@Link module
4812013038 GPS module
Dyn@lyzer
1
2
3
4
5
8
8
9
9
10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
1
Edgecutter,module
Edge cutter, module
2
Cuttingdiscmodule
Cutting disc module
3
Pressingroller,module
Pressing roller, module
4
Hydraulicvalvemodule
Hydraulic valve module
5
Disc/Rollerholder
Disc/Roller holder
8
4700484103
Hydraulic hose
9
4700484104
Hydraulic hose
10
4700792395
Switch
11
4700792396
Switch
12
4700891374
O-ring
