1
2
3
4
5
6
7
8
8
9
10
11
12
13
Позиция на иллюстрации
Заводской номер детали
Название детали
1
4700395924
Hydraulic valve
2
Valveblock
Valve block, cpl
3
4700940572
Shuttle valve
4
4812159770
Check valve
5
4812160491
Brake release valve
6
4700950571
Priority valve
7
4700950572
Pressure relief valve
8
4700950570
Solenoid valve
8
4812156662
Coil
9
4812156787
Fan proportional valve
10
Brakereleasepump
Brake release pump
11
4812160160
Brake pressure relief valve
12
4812157585
Orifice with wire
13
4812159762
Orifice
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
