Bearing unit
Edge cutter, left
Holder, edge cutter
Holder module
Pressing roller, module
Cutting disc module
1
2
3
4
4
5
6
7
8
9
10
11
Позиция на иллюстрации
Заводской номер детали
Название детали
1
4812123307
Shaft
2
4700391012
Bearing housing
3
4700391010
Bearing cover
4
4700792385
Taper roller bearing
5
4700792384
Radial lip-type seal
6
4700136012
Lock washer
7
4700135012
Shaft nut
8
4700900512
O-ring
9
4700903891
Stud
10
4700508018
Screw
11
Lubegrease
Lube grease
