1
2
2
2
2
3
4
5
6
7
8
9
10
11
13
Позиция на иллюстрации
Заводской номер детали
Название детали
1
4812119368
Platform with 4-post ROPS
2
4812121000
Shock absorber Green
3
4700359998
Back-up ring
4
4700393525
Holder
5
4700903633
Screw
6
4700500194
Hex. screw
7
4700904233
Steel plain washer
8
0291112843
Lock nut
9
Decalsbasickit
Decals basic kit
10
4700903459
Decal SAFETY
11
4812125363
Safety decal RISK OF CRUSHING
13
ManualBox
Manual Box
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
