Каталог запасных частей к технике: DYNAPAC CC2200. Decals

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
2
2
3
3
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
11
11
12
13
14
14
15
16
17
17
18
19
20
20
21
21
22
23
24
25
26
26
27
27
28
29
30
31
32
33
34
36
37
38
38
39
39
39
39
40
40
40
40
Позиция на иллюстрации Заводской номер детали Название детали
1 4812127716 Decal
2 4812128484 Decal model code combined
2.1 Decal Decal
2.2 Decal Decal
3 4700382751 Decal SECURING POINT/TIE DOWN
4 4700904870 Lifting data plate
5 4700624005 Blind rivet 3,2x6,1
6 4700357587 Label, lift point
7 4700908229 Safety decal
8 4812130231 Reflector, white
9 4812128485 Decal model code combined
9.1 Decal Decal
9.2 Decal Decal
10 4812130232 Reflector, red
11 4700903422 Safety decal CRUSH AREA
12 Productidentificationplate Product identification plate
13 4700624005 Blind rivet 3,2x6,1
14 4700272372 Decal HYDRAULIC OIL
14 4700792772 Decal BIO HYDRAULIC OIL PANOLIN
15 4700272373 Decal HYDRAULIC LEVEL
16 4700388449 Decal ENGINE COOLANT FILL
17 4700791642 Decal WARNING Use of starting fluid prohib.
18 4700903459 Decal SAFETY
19 4700903425 Safety decal READ SAFETY INSTRUCTIONS
20 4700903423 Safety label, Rotating engine components
21 4700903424 Safety decal HOT SURFACE
22 4700904835 Decal BATTERY POWER
23 4700393959 Decal Battery voltage 24V
24 4700991657 Decal WATER
25 4811000344 Decal, low sulfur
26 4812130233 Reflector, yellow
27 4700791276 Decal Sound power level 106dB
27 4700791277 Decal Sound power level 107dB
28 4700904165 Safety decal Toxic gases
29 4700904083 Safety decal
30 4700394596 Decal Risk location
31 4700394594 Decal Risk location
32 4700394593 Decal Risk location
33 4700394595 Decal Risk location
34 4700904895 Safety decal Brake release
36 4811000345 Decal ULTRA LOW SULFUR FUEL ONLY
37 4812127716 Decal
38 4812127714 Decal FAYAT DYNAPAC 350 WH
38 4812127716 Decal
39 4700792749 Plate"TIE DOWN POINT"
40 4812126129 Adhesive tape
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
