Hydraulic hoses
Hydraulic hoses
Driving lights assy
Dyn@lyzer
Dyn@Link module
4812013038 GPS module
DCM Compaction meter with Evib
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
16
Позиция на иллюстрации
Заводской номер детали
Название детали
1
4700792822
Quick disconnect coupling
2
4700792046
Quick disconnect coupling
3
4700792820
Quick disconnect coupling
4
4700904727
Adapter
5
4700791541
Straight connector
6
4700343872
Hose clamp
7
4700335914
Cover plate
8
4700396657
Hose clamp
9
4700396655
Hose clamp
10
4700397609
Hose guard
11
4812110272
Hose guard
12
4700904230
Washer
13
4700500077
Screw
14
4700792817
Hexagon nut with flange
15
4700484369
Hydraulic hose
16
4700484371
Hydraulic hose
