Позиция на иллюстрации
Заводской номер детали
Название детали
1
4812110899
Cable harness
1
4812115291
Cable harness
2
4700792422
Relay
3
4700792210
Screw torx
4
4812110902
Cable harness
5
4700901227
Fuse
6
4811000163
Flash relay
7
4700901226
Fuse
8
Drivinglights
Driving lights
9
Steeringcolumnswitch
Steering column switch module
10
Cableharness
Cable harness
11
Registrationplatelight
Registration plate light
12
Drivinglights
Driving lights
13
4812110903
Cable harness Std
13
4812110904
Cable harness Off-set
14
Turnsignals
Turn signals
