Chip spreader
Chip spreader
Bracket module
Hydraulic valve module
Hydraulic hoses
Hydraulic hoses
Driving lights assy
Dyn@lyzer
Dyn@Link module
4812013038 GPS module
DCM Compaction meter with Evib
1
2
3
4
5
6
7
8
9
9
10
11
12
12
Позиция на иллюстрации
Заводской номер детали
Название детали
1
4700792792
Switch
2
4700397295
Cable harness
3
Chipspreader
Chip spreader, mount
4
Bracket
Bracket
5
4812110391
Protective plate
6
4812110385
Marking tape
7
4812110387
Marking tape
8
Hydraulicvalve
Hydraulic valve
9
4700397497
Cable harness
10
Hydraulichoses
Hydraulic hoses, frame
11
Hydraulichoses
Hydraulic hoses, frame
12
Drivinglights
Driving lights
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
