Каталог запасных частей к технике: DYNAPAC CC1300C. Vibration system
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
20
21
22
23
24
25
26
27
28
29
30
31
32
33
33
34
35
36
37
38
38
38
38
38
38
38
38
38
38
38
38
39
40
41
42
43
44
44
44
44
44
44
45
46
47
48
49
50
51
52
53
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4812121922 | Hydraulic pump | |
| 2 | 4700379458 | Gasket | |
| 3 | 4700792409 | Hexagon screw with flange | |
| 4 | 4700903456 | Pipe clamp | |
| 5 | 4700160016 | O-ring | |
| 6 | 4700902287 | Nut | |
| 7 | 4812124236 | Flange | |
| 8 | 4700904556 | Steel plain washer | |
| 9 | 4700500067 | Screw | |
| 10 | 4700904230 | Washer | |
| 11 | 4700500078 | Hex. screw | |
| 12 | 4700586003 | Hexagon lock nut | |
| 13 | 4700791415 | Elbow | |
| 14 | 4700901692 | Screw | |
| 15 | 4700480124 | Washer | |
| 16 | 4812124367 | Hydraulic hose | |
| 17 | 4700480124 | Washer | |
| 18 | 4700791699 | Elbow 90° | |
| 20 | 4700162006 | Seal ring | |
| 21 | 4812123298 | Plug | |
| 22 | 4812121571 | CHECK VALVE | |
| 23 | 4700791745 | Elbow 90, O-ring with swivel | |
| 24 | 4700923405 | Measuring nipple | |
| 25 | 4700792219 | Straight connector | |
| 26 | 4700791792 | Tee-connector | |
| 27 | 4700371314 | Hose clamp | |
| 28 | 4700901832 | Screw | |
| 29 | 4700508029 | Cylinder screw | |
| 30 | 4700603018 | Washer | |
| 31 | 4812118173 | HYDRAULIC MOTOR | |
| 32 | 4700791397 | Elbow 90, O-ring | |
| 33 | 4700791699 | Elbow 90° | |
| 34 | 4700160031 | O-ring | |
| 35 | 4812122804 | Hydraulic hose | |
| 36 | 4812121712 | HYDRAULIC HOSE | |
| 37 | 4812119870 | Hydraulic hose | |
| 38 | 4700902379 | Edge trim | |
| 38 | 4700902379 | Edge trim | |
| 38 | 4700902379 | Edge trim | |
| 39 | 4700371313 | Hose clamp | |
| 40 | 4700902295 | Clamp | |
| 41 | 4812122580 | Hydraulic hose | |
| 42 | 4700902295 | Clamp | |
| 43 | 4700791398 | Elbow 90, O-ring | |
| 44 | 4700358486 | Rubber strip | |
| 44 | 4700358486 | Rubber strip | |
| 45 | 4700989151 | Oil level glass | |
| 46 | 4700232122 | Plug | |
| 47 | 4812122570 | Hydraulic hose | |
| 48 | 4700313008 | Hose clamp | |
| 49 | 4812124919 | Hydraulic hose | |
| 50 | 4700357139 | Connector | |
| 51 | 4700357138 | Ventilating filter | |
| 52 | 4700791745 | Elbow 90, O-ring with swivel | |
| 53 | 4700791843 | Elbow 90, O-ring with swivel |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
