Каталог запасных частей к технике: DYNAPAC CC1300C. Electrical equipment
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
16
17
18
19
20
21
22
23
24
25
26
27
27
27
28
28
29
29
29
30
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | Horn module | Horn module | |
| 2 | Battery module | Battery module | |
| 3 | Battery disconnector | Battery disconnector, 2-pole | |
| 4 | ECU module | ECU module | |
| 5 | 4812122191 | Wiring harness | |
| 6 | 4811000320 | Battery cable | |
| 7 | 4811000321 | Battery cable | |
| 8 | 4811000323 | Connection cable | |
| 9 | 4811000322 | Connection cable | |
| 10 | 4700791739 | Emergency stop | |
| 11 | 4811000128 | Decal | |
| 12 | 4700389840 | Connector wFixing collar | |
| 13 | 4700791723 | Connector N/C | |
| 14 | 4700903741 | Fuse | |
| 15 | 4700901227 | Fuse | |
| 16 | 4700901228 | Fuse | |
| 17 | 4700792441 | Cable tie with holder | |
| 18 | 4700313041 | Cable tie | |
| 19 | 4700904229 | Washer | |
| 20 | 4700500022 | Hex. screw | |
| 21 | 4700586003 | Hexagon lock nut | |
| 22 | 4700901230 | Fuse | |
| 23 | 4700904039 | Fuse | |
| 24 | 4811000312 | Starter relay | |
| 25 | 4700903956 | Relay | |
| 26 | 4700904448 | Relay | |
| 27 | 4700904281 | Washer | |
| 28 | 4700500006 | Hex. screw | |
| 29 | 4700586001 | Lock nut | |
| 30 | 4700500007 | Screw |
