Каталог запасных частей к технике: DYNAPAC CC1300C. Decals
1
1
3
3
7
7
8
8
10
11
12
12
13
13
14
14
20
20
26
26
27
27
28
28
33
33
34
34
34
34
35
36
36
37
37
38
38
40
42
45
47
48
48
49
50
51
51
52
52
53
53
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4700903459 | Decal SAFETY | |
| 3 | 4700903425 | Safety decal READ SAFETY INSTRUCTIONS | |
| 7 | 4700904870 | Lifting data plate | |
| 8 | 4700357587 | Label, lift point | |
| 10 | 4812120315 | Decal "COMPACTING ROCKS" Right side | |
| 11 | 4812120314 | Decal "COMPACTING ROCKS" Left side | |
| 12 | 4700991657 | Decal WATER | |
| 13 | 4700903422 | Safety decal CRUSH AREA | |
| 14 | 4811000344 | Decal, low sulfur | |
| 14 | 4811000345 | Decal ULTRA LOW SULFUR FUEL ONLY | |
| 20 | 4812120416 | Decal "MODEL CODE" CC1300 | |
| 26 | 4700903423 | Safety label, Rotating engine components | |
| 27 | 4700903424 | Safety decal HOT SURFACE | |
| 28 | 4700272372 | Decal HYDRAULIC OIL | |
| 28 | 4700792772 | Decal BIO HYDRAULIC OIL PANOLIN | |
| 33 | 4700908229 | Safety decal | |
| 34 | 4700382751 | Decal SECURING POINT/TIE DOWN | |
| 35 | 4700904835 | Decal BATTERY POWER | |
| 36 | 4700377742 | Reflector, red | |
| 37 | 4700377744 | Reflector, yellow | |
| 38 | 4700377743 | Reflector, white | |
| 40 | 4700791275 | Decal Sound power level 105dB | |
| 42 | 4811000128 | Decal | |
| 45 | 4700272373 | Decal HYDRAULIC LEVEL | |
| 46 | 4700791094 | Decal RUS 127 approved Option | |
| 47 | 4812124830 | Decal "Start instruction" | |
| 48 | 4812116992 | Decal TYRE PRESSURE | |
| 49 | 4700904399 | Decal Risk location | |
| 50 | 4700904396 | Decal Risk location | |
| 51 | 4812120119 | Decal Atlas Copco Black | |
| 52 | 4812120122 | Decal AC logotype White, H=190 | |
| 53 | 4812120123 | Decal Atlas Copco Black, H=118 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
