Каталог запасных частей к технике: DYNAPAC CC1300C. Propulsion system To 0A014957 incl. 0A014959 - 0A014960

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
2
4
4
4
4
5
5
6
6
7
8
9
9
10
10
11
12
13
14
15
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
31
32
32
33
34
35
35
36
37
38
38
39
40
41
42
43
44
45
45
46
46
47
47
48
48
48
49
50
51
52
53
54
55
56
57
58
60
61
61
62
63
79
80
80
80
81
81
82
82
82
83
83
84
84
85
86
86
87
87
88
89
89
90
91
Позиция на иллюстрации Заводской номер детали Название детали
1 4700372352 Hydraulic pump, propulsion
2 4700357022 Hydraulic motor, propulsion, drum
4 4700483321 Hydraulic hose
5 4700901155 Connector
6 4700483039 Hydraulic hose
7 4700500046 Hex. head screw
8 4700904703 Plain washer
9 4811000084 Hydraulic hose
10 4700482452 Hydraulic hose
11 4700373402 Flange
12 4700234218 Tee-connector
13 4700813444 Elbow 90, O-ring
14 4700334135 Tee-connector
15 4700483118 Hydraulic hose
16 4700334156 Adapter
17 4700901156 Connector
18 4700903925 Connector
19 4700334238 Elbow 90 o-ring
20 4700334235 Elbow 90
21 4812113327 Hydraulic oil filter
22 4700902377 Cover
23 4700902378 Insert
24 4700902229 Sealing
25 4700902230 O-ring
26 4700902231 O-ring
27 4700902232 O-ring
28 4700903247 Filter element
29 4700901313 Plug
30 4700230277 Copper washer
31 4700508029 Cylinder screw
32 4700615044 Washer
33 4700928022 Screw
34 4700384114 Spacer
35 4700482553 Hydraulic hose
36 4700371313 Hose clamp
37 4700371314 Hose clamp
38 4700904229 Washer
39 4700500021 Hex. screw
40 4812110281 Junction block
41 4700375616 Spacer sleeve
42 4700313102 Cable ties
43 4700508096 Hexagon socket head cap screw
44 4700586003 Hexagon lock nut
45 4700904230 Washer
45 4700904230 Washer
46 4700500068 Screw
47 4700902379 Edge trim
48 4700357111 Rubber cloth
49 4700357112 Cover plate
50 4700355869 Spacer sleeve
51 4700586018 Lock nut
52 4700902233 Threaded stud
53 4700927637 Hexagon socket countersunk screw
54 4700921022 Hose clamp
55 4700334155 Elbow 90
56 4700925723 Connector
57 4700947698 Hex. head screw
58 4700232070 Plug
60 4700921099 Clamp
61 4700813443 O-ring
62 4700901157 Measuring nipple
63 4700904232 Steel plain washer
79 4700334197 Connector elbow 90 JIC
80 4700483174 Hydraulic hose
81 4700483175 Hydraulic hose
82 4700234860 Connector
83 4700234233 Adapter
84 4700375632 Hydraulic motor, propulsion
85 4700500269 Screw
86 4700904231 Washer
87 4812110490 Holder
88 4700902379 Edge trim
89 4700483289 Hydraulic hose
90 4812111881 Bracket
91 4811000456 Screw
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
