1
2
3
4
5
6
7
8
9
10
Позиция на иллюстрации
Заводской номер детали
Название детали
1
4700357567
Battery switch, cpl
2
4700903732
Screw
3
4812122432
Bracket
4
4700391115
Spacer sleeve
5
4812110560
Power socket
6
4700586003
Hexagon lock nut
7
4700904036
Fuse holder
8
4700904281
Washer
9
4700500060
Screw
10
4700586001
Lock nut
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
