Каталог запасных частей к технике: DYNAPAC CC1300. 4812120091 Hydraulic pump

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
19
19
19
20
21
22
23
24
25
26
26
27
28
Позиция на иллюстрации Заводской номер детали Название детали
1 Housing Housing
2 Shaft Shaft
3 Pin Pin
4 Swash plate Swash plate
5 Retaining wire Retaining wire
6 Pin Pin
7 Screw Screw
8 Retaining wire Retaining wire
9 Distribution block Distribution block
10 Ring Ring
11 Distribution valve Distribution valve
12 Pin Pin
13 Pin Pin
14 Bushing Bushing
15 4812161278 Seal kit, overhaul
16 4812161282 Pump shaft kit
17 Repair kit, housing Repair kit, housing
18 Repair kit Repair kit
19 Control valve, kit Control valve, kit
19.1 4812160799 Brake valve
19.1.1 4812161797 Stop solenoid
20 Plug Plug connector see engine Gr. 9
21 Repair kit, control valve Repair kit, control valve
22 4812161990 Control unit
23 Rotating group, kit Rotating group, kit
24 Repair kit, valve block Repair kit, valve block
25 Gerotor kit Gerotor kit
26 Pressure control valve Pressure control valve
27 4812161058 Low pressure relief valve kit
28 Repair kit, valve block Repair kit, valve block
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
