Каталог запасных частей к технике: DYNAPAC CC1200CC. Sprinkler system
1
2
3
4
5
6
7
8
10
11
12
12
12
12
13
13
13
14
14
15
15
16
18
20
20
21
21
21
21
21
21
21
21
21
21
24
26
28
29
30
31
33
34
35
37
38
41
41
42
42
43
43
44
45
51
51
52
54
56
56
57
58
58
59
60
61
61
62
70
71
71
72
72
73
73
74
74
74
74
74
75
75
75
75
75
75
75
83
83
84
86
87
88
90
90
91
97
98
130
131
132
133
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4812113822 | Water pump | |
| 2 | 4812111325 | Water filter | |
| 3 | 4700791959 | O-ring | |
| 4 | 4700791949 | Filter element | |
| 5 | 4700791568 | Gasket | |
| 6 | 4700379009 | Valve | |
| 7 | 4700357395 | Holder plate | |
| 8 | 4700926911 | Rubber strip | |
| 10 | 4812113066 | Bracket | |
| 11 | 4812113067 | Bracket | |
| 12 | 4700500053 | Hex. screw | |
| 12 | 4700500053 | Hex. screw | |
| 13 | 4700904229 | Washer | |
| 14 | 4700901431 | Hose connection | |
| 15 | 4700923734 | Hose connection | |
| 16 | 4812111330 | Hose connection | |
| 18 | 4700901432 | Hose connection | |
| 20 | 4700923735 | Hose connection | |
| 21 | 4700313002 | Hose clamp | |
| 22 | 4700903478 | Absorbent | |
| 24 | 4700500028 | Screw | |
| 26 | 4812112074 | Plastic hose | |
| 28 | 4700500190 | Screw | |
| 29 | 4700358846 | Strainer | |
| 30 | 4812112074 | Plastic hose | |
| 31 | 4700287713 | Solenoid valve | |
| 33 | 4812112074 | Plastic hose | |
| 34 | 4812111969 | Sprinkler tank, cpl. | |
| 35 | 4700359003 | Tank Cap | |
| 37 | 4811000168 | Cap | |
| 38 | 4700392229 | Plane gasket | |
| 41 | 4700392230 | Grommet | |
| 42 | 4700160219 | O-ring | |
| 43 | 4700392232 | Nut | |
| 44 | 4700392227 | Swivel nut | |
| 45 | 4700792600 | O-ring 70 | |
| 51 | 4700904640 | Washer | |
| 52 | 4700792779 | Swivel nut | |
| 54 | 4812112074 | Plastic hose | |
| 56 | 4700924544 | Hose connection | |
| 57 | 4700925599 | Ball valve | |
| 58 | 4812112831 | Ball valve | |
| 58 | 4812126907 | Ball valve | |
| 59 | 4700160313 | O-ring | |
| 60 | 4812111331 | Reducer nipple | |
| 61 | 4700379753 | Gasket | |
| 62 | 4812112451 | Hose connection | |
| 70 | 4700904557 | Washer | |
| 71 | 4812126431 | Heat protection | |
| 71 | 4812117746 | Heat protection | |
| 72 | 4700792072 | End plug | |
| 73 | 4700233215 | Ball valve | |
| 74 | 4700392011 | Spraying nozzle, cpl | |
| 74 | 4700392509 | Retainer, nozzle, strainer, yellow | |
| 74 | 4700392510 | Gasket | |
| 74 | 4700393697 | Nozzle and strainer, yellow | |
| 75 | 4812124323 | Cap, blue | |
| 75 | 4812124327 | Nozzle | |
| 75 | 4700160268 | O-ring | |
| 75 | 4812124324 | Strainer | |
| 75 | 4812124321 | Spraying nozzle, cpl | |
| 75 | 4812124325 | Gasket | |
| 83 | 4700791977 | Hose connection | |
| 84 | 4700901191 | Protective hose | |
| 86 | 4812112074 | Plastic hose | |
| 87 | 4812112074 | Plastic hose | |
| 88 | 4700500020 | Hex. screw | |
| 90 | 4812112994 | Bracket | |
| 90 | 4812124835 | Bracket | |
| 91 | 4812113781 | Rubber strip | |
| 97 | 4700393542 | Hose connection | |
| 98 | 4700792600 | O-ring 70 | |
| 130 | 4812118056 | Lock plate | |
| 131 | 4700370699 | Lock w key | |
| 132 | 4700904228 | Steel plain washer | |
| 133 | 4811000457 | Thread rolling screw |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
