Каталог запасных частей к технике: DYNAPAC CC1200C VI. Vibration system, external vibration valve - common
1
2
3
4
5
6
7
8
9
10
11
12
12
13
13
13
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
31
32
33
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4812125730 | Hydraulic hose | |
| 2 | 4812125731 | Hydraulic hose | |
| 3 | 4700483906 | Hydraulic hose | |
| 4 | 4812125732 | Hydraulic hose | |
| 5 | 4812125733 | Hydraulic hose | |
| 6 | 4812125734 | Hydraulic hose | |
| 7 | 4812125735 | Hydraulic hose | |
| 8 | 4812125736 | Hydraulic hose | |
| 9 | 4812125737 | Hydraulic hose | |
| 10 | 4812125738 | Hydraulic hose | |
| 11 | 4812114492 | Bulkhead union | |
| 12 | 4700791397 | Elbow 90, O-ring | |
| 13 | 4700791699 | Elbow 90° | |
| 14 | 4812113633 | Flange connector | |
| 15 | 4700904774 | O-ring | |
| 16 | 4700508027 | Screw | |
| 17 | 4700791410 | Straight o-ring connector | |
| 18 | 4700791843 | Elbow 90, O-ring with swivel | |
| 19 | 4700791841 | Elbow 90 orfs | |
| 20 | 4700791796 | Elbow 45, O-ring with swivel | |
| 21 | 4700900229 | Measuring fitting | |
| 22 | 4700791744 | Adapter | |
| 23 | 4812125501 | Bracket | |
| 24 | 4700904229 | Washer | |
| 25 | 4700500053 | Hex. screw | |
| 26 | 4700904557 | Washer | |
| 27 | 4700500028 | Screw | |
| 28 | 4812125469 | Flange connector | |
| 29 | 4700160016 | O-ring | |
| 30 | 4700923378 | Hose clamp | |
| 31 | 4700904556 | Steel plain washer | |
| 32 | 4700508048 | Hexagon socket head cap screw | |
| 33 | 4700791416 | Elbow 45, O-ring | |
| 34 | 4700792389 | Elbow 45 orfs | |
| 35 | 4700792602 | Cable tie with holder | |
| 36 | 4812127309 | Hydraulic pump | |
| 37 | 4700379458 | Gasket | |
| 38 | 4700500078 | Hex. screw | |
| 39 | 4700904230 | Washer | |
| 40 | 4700902287 | Nut | |
| 41 | 4812118172 | Hydraulic motor | |
| 42 | 4700603018 | Washer | |
| 43 | 4700508029 | Cylinder screw | |
| 44 | 4812125749 | Hydraulic valve | |
| 45 | 4700791414 | T-connection, O-ring with swivel | |
| 46 | 4700791847 | Straight connector | |
| 47 | 4700923405 | Measuring nipple | |
| 48 | Hydraulic motor | Hydraulic motor, Cpl | |
| 49 | 4700904229 | Washer | |
| 50 | 4700500021 | Hex. screw | |
| 51 | 4700904735 | Steel plain washer | |
| 52 | 4700508002 | Screw | |
| 53 | 4700160031 | O-ring |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
