Каталог запасных частей к технике: DYNAPAC CC1200C VI. Sprinkler pump
1
2
2
3
4
4
5
5
5
6
6
6
6
7
9
9
9
9
9
9
9
9
9
9
9
9
10
10
11
11
12
12
12
13
14
15
16
16
17
18
18
19
19
20
20
21
22
22
23
23
24
24
25
25
26
27
28
29
30
31
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4812125973 | Bracket | |
| 2 | 4700904229 | Washer | |
| 3 | 4700500053 | Hex. screw | |
| 4 | 4812125871 | Sprinkler pump | |
| 5 | 4700904640 | Washer | |
| 6 | 4700234931 | Adapter | |
| 7 | 4700923735 | Hose connection | |
| 8 | 4812112074 | Plastic hose | |
| 9 | 4700313002 | Hose clamp | |
| 10 | 4700377611 | Straight connector | |
| 11 | 4700287713 | Solenoid valve | |
| 12 | 4700901432 | Hose connection | |
| 13 | 4700500021 | Hex. screw | |
| 14 | 4700570005 | Hex. nut | |
| 15 | 4700500019 | Hex. screw | |
| 16 | 4812111325 | Water filter | |
| 17 | 4700500090 | Screw | |
| 18 | 4812111330 | Hose connection | |
| 19 | 4700480852 | O-ring 70 | |
| 20 | 4700792779 | Swivel nut | |
| 21 | 4812112074 | Plastic hose | |
| 22 | 4700160313 | O-ring | |
| 23 | 4812111331 | Reducer nipple | |
| 24 | 4812126907 | Ball valve | |
| 25 | 4812112451 | Hose connection | |
| 26 | 4812112074 | Plastic hose | |
| 27 | 4812112074 | Plastic hose | |
| 28 | 4812112074 | Plastic hose | |
| 29 | 4700233215 | Ball valve | |
| 30 | 4812112074 | Plastic hose | |
| 31 | 4700903192 | Grommet |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
