Каталог запасных частей к технике: DYNAPAC CC1200C VI. 4812126969 Hydraulic pump

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
10
10
11
12
13
14
14
15
17
17
19
20
20
22
23
25
26
27
28
29
Позиция на иллюстрации Заводской номер детали Название детали
4812126969 4812126969 Hydraulic pump
1 Shaft seal kit Shaft seal kit
2 Bearing kit Bearing kit
3 Rotating group kit Rotating group kit
4 Valve plate Valve plate
5 Swash plate Swash plate
6 Shaft Shaft
7 Housing Housing
8 Pin Pin
9 Retaining ring Retaining ring
10 Screw Screw
11 Retaining lever Retaining lever
12 Pin Pin
13 Block slide hydraulic kit Block slide hydraulic kit
14 Hydraulic servo control kit Hydraulic servo control kit
15 Restrictor kit Restrictor kit
17 High pressure relief valve kit High pressure relief valve kit
19 Pin Pin
20 High pressure relief valve kit High pressure relief valve kit
22 Low pressure relief valve kit Low pressure relief valve kit
23 Screw bypass kit Screw bypass kit
25 Charge pump kit Charge pump kit
26 Key Key
27 Coupling shaft Coupling shaft
28 End cover End cover
29 Direct mechanical controls with return spring Direct mechanical controls with return spring
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
