Каталог запасных частей к технике: DYNAPAC CC1200C VI. 4812120558 Hydraulic motor

Тип техники

Марка

Модель

Схема

1

1

1

2

3

4

5

6

7

8

9

10

11

11

11

11

12

13

14

14

15

16

18

19

20

21

22

23

23

23

23

23

24

24

24

25

26

27

27

27

28

29

30

31

32

33

34

34

34

35

35

35

35

35

Позиция на иллюстрации	Заводской номер детали		Название детали
4812120558	4812120558		Hydraulic motor
1	4812162174		Repair kit
1	Brake disc		Brake disc
1	Brake disc		Brake disc
2	4812162175		Shim
3	4812162176		Screw
4	4812162177		Brake piston
5	4812162178		Washer
6	4812162179		Snap ring
7	Shield		Shield
8	4812162181		Screw
9	Repair kit		Repair kit
10	4812160275		Repair kit
11	Repair kit		Repair kit
11	Repair kit		Repair kit
11	Bushing		Bushing
11	4812162182		Seal
12	4812162183		Brake housing
13	4812162184		Brake shaft
14	4812162185		Seal kit
14	Repair kit		Repair kit
15	4812162186		Seal kit
16	4812162187		Plug
18	4812162188		Screw
19	4812162189		Cover
20	4812162190		Pin
21	4812162191		Seal kit
22	4812162192		Valve
23	Roller		Roller
23	Repair kit		Repair kit
23	Piston		Piston
23	Piston bushing		Piston bushing
23	4812162193		Piston
24	4812162194		Repair kit
24	Lunambule		Lunambule
24	Clip		Clip
25	Cylinder block		Cylinder block
26	4812162195		Seal
27	4812162196		Seal kit
27	Plug		Plug connector see engine Gr. 9
27	Repair kit		Repair kit
28	4812162197		Cam
29	4812162198		Bearing
30	4812162199		Bearing support
31	4812162251		Bearing
32	4812162252		Bolt
33	4812162253		Shaft
34	4812162254		Repair kit
34	Repair kit		Repair kit
34	Repair kit		Repair kit
35	Repair kit		Repair kit
35	Shim		Shim
35	Guide ring		Guide ring
35	Snap ring		Snap ring
35	4812162255		Repair kit

Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
