Каталог запасных частей к технике: DYNAPAC CC1200C Plus. Sprinkler system

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
2
3
3
4
4
5
5
6
6
7
8
10
11
12
12
12
12
12
12
13
13
13
13
14
14
15
15
15
15
16
18
20
21
21
21
21
21
21
21
21
21
21
21
21
21
21
26
26
28
28
29
30
31
31
33
34
35
37
38
41
41
42
43
43
44
45
46
51
51
51
51
51
51
52
52
54
56
56
57
57
58
59
59
60
60
61
61
61
62
70
70
70
71
72
73
74
75
76
77
83
87
88
90
91
93
95
97
98
100
100
101
103
103
104
104
105
106
107
108
109
111
112
113
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
114
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
115
116
117
118
119
120
121
130
131
132
133
Позиция на иллюстрации Заводской номер детали Название детали
1 4812113822 Water pump
2 4812111325 Water filter
3 4700791959 O-ring
4 4700791949 Filter element
5 4700791568 Gasket
6 4700379009 Valve
7 4700357395 Holder plate
8 4700926911 Rubber strip
10 4812113066 Bracket
11 4812113067 Bracket
12 4700500053 Hex. screw
13 4700904229 Washer
14 4700901431 Hose connection
15 4700923734 Hose connection
16 4812111330 Hose connection
18 4700901432 Hose connection
20 4700923735 Hose connection
21 4700313002 Hose clamp
22 4700903478 Absorbent
26 4812112074 Plastic hose
28 4700500190 Screw
29 4700358846 Strainer
30 4812112074 Plastic hose
31 4700287713 Solenoid valve
33 4812112074 Plastic hose
34 4812111969 Sprinkler tank, cpl.
35 4700359003 Tank Cap
36 4700937053 Plug, cpl
37 4811000168 Cap
38 4700392229 Plane gasket
41 4700392230 Grommet
42 4700160219 O-ring
43 4700392232 Nut
44 4700392227 Swivel nut
45 4700792600 O-ring 70
46 4812112074 Plastic hose
51 4700904640 Washer
52 4700792779 Swivel nut
54 4812112074 Plastic hose
56 4700924544 Hose connection
57 4700925599 Ball valve
58 4812112831 Ball valve
59 4700160313 O-ring
60 4812111331 Reducer nipple
61 4700379753 Gasket
62 4812112451 Hose connection
70 4700904557 Washer
71 4812117746 Heat protection
72 4700792072 End plug
73 4700233215 Ball valve
74 4700392011 Spraying nozzle, cpl
75 4700392509 Retainer, nozzle, strainer, yellow
76 4700392510 Gasket
77 4700392508 Housing
83 4700791977 Hose connection
84 4700901191 Protective hose
86 4812112074 Plastic hose
87 4812112074 Plastic hose
88 4700500020 Hex. screw
90 4812112994 Bracket
91 4812113781 Rubber strip
92 4700313041 Cable tie
93 4700791182 Nut
94 4700480852 O-ring 70
95 4700500022 Hex. screw
97 4700375745 Sprinkling tank
98 4700902268 Cap
100 4700500028 Screw
101 4700375805 Holder plate
103 4700924996 Hose connection
104 4812112074 Plastic hose
105 4700901432 Hose connection
106 4812112074 Plastic hose
107 4700902286 Lock nut
108 4700480852 O-ring 70
109 4812111329 Hose connebtion swivel
111 4700921099 Clamp
112 4812112074 Plastic hose
113 4700384300 Sprinkler pipe
114 4700928781 Sprinkler, cpl
114 4700923680 Nozzle clamp
114 4700903010 Nylon ring
114 4700902869 Strainer
114 4700904116 Gasket
114 4700902910 Nozzle body
114 4700902868 Coupling, red
115 4700904228 Steel plain washer
115 4700923876 Clamp
115 4700923859 Cover plate
115 4700500016 Screw
115 4700902285 Nut
116 4700923684 Hose connection
117 4700923683 Plug
118 4700357819 Rubber cloth
119 4700791977 Hose connection
120 4700791974 Plug threaded
121 4812112009 Bracket
130 4812118056 Lock plate
131 4700370699 Lock w key
132 4700904228 Steel plain washer
133 4811000457 Thread rolling screw
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
