Каталог запасных частей к технике: DYNAPAC CA6500. 4812122932 Hydraulic motor

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
6
7
7
8
8
8
9
9
9
10
11
12
13
14
17
18
19
20
21
22
23
24
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
38
41
41
42
42
43
51
52
53
53
54
54
55
55
56
57
58
59
60
61
62
63
Позиция на иллюстрации Заводской номер детали Название детали
1 Solenoid On/off Solenoid On/off
2 Coil kit Coil kit
3 4700923087 O-ring
4 Control housing Control housing, 2 position
5 4812156999 Shuttle valve assembly
6 Plug Plug connector see engine Gr. 9
7 4700923087 O-ring
8 4700908426 Plug, cpl
9 4700908440 O-ring
10 4812157051 Spool
11 4812157052 Spring
12 4812158452 Screw
13 4700902944 Screw
14 4812157053 Control seal
17 End cap End cap
18 4812157076 Servo piston
19 Button head screw Button head screw
20 Plug assembly Plug assembly
21 O-ring O-ring
22 4700902944 Screw
23 4700902928 Plug
24 O-ring O-ring
25 4700935525 O-ring
26 4700935524 Seal plug
27 4812157077 Valve segment assembly
28 Synch shaft assembly Synch shaft assembly
29 Cylinder block assembly Cylinder block assembly
30 4700902930 Bearing plate
31 Shaft assembly Shaft assembly
32 Set screw Set screw
33 4700909525 Seal nut
34 4700902996 Plastic cap, green
35 Housing, cartridge with speed sensor port Housing, cartridge with speed sensor port
36 Lip seal Lip seal
37 4812157078 Retaining ring
38 Pin Pin
41 Plug assembly Plug assembly
42 O-ring O-ring
43 Plain washer Plain washer
50 Loop flushing Loop flushing
51 4812158153 Seal kit,cpl
52 4812157060 Spool
53 4812157061 Spring
54 Plug assembly Plug assembly
55 O-ring O-ring
56 4812157062 Loop flushing relief valve
57 4812157063 O-ring
58 Orifice plug Orifice plug
59 O-ring O-ring
60 4812157073 Speed sensor
61 Screw Screw
62 4700908440 O-ring
63 Plug assembly Plug assembly
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
