Каталог запасных частей к технике: DYNAPAC CA6500. 4812112211 Rear axle motor

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
6
7
7
8
8
8
9
9
9
10
11
12
13
14
15
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
34
35
36
37
37
38
38
39
40
41
42
43
44
45
50
51
Позиция на иллюстрации Заводской номер детали Название детали
1 4812157074 Solenoid On/off
2 4812157075 Coil kit
3 O-ring O-ring
4 Control housing, 2 position Control housing
5 4812156999 Shuttle valve assembly
6 Plug assembly Plug assembly
7 O-ring O-ring
8 Plug assembly Plug assembly
9 O-ring O-ring
10 4812157051 Spool
11 4812157052 Spring
12 Screw Screw
13 Screw Screw
14 4812157053 Control seal
15 Orifice plug Orifice plug
16 End cap End cap
17 4812157076 Servo piston
18 Button head screw Button head screw
19 Plug assembly Plug assembly
20 O-ring O-ring
21 Screw Screw
22 Plug assembly Plug assembly
23 O-ring O-ring
24 O-ring O-ring
25 Piston ring Piston ring
26 4812157077 Valve segment assembly
27 Synch shaft assembly Synch shaft assembly
28 Cylinder block assembly Cylinder block assembly
29 4700902930 Bearing plate
30 Shaft assembly Shaft assembly
31 Housing Housing
32 4700945757 Shaft seal
33 4812157078 Retaining ring
34 Pin Pin
35 Shaft locating plug assembly Shaft locating plug assembly
36 O-ring O-ring
37 Plug assembly Plug assembly
38 O-ring O-ring
39 4812157079 Gasket
40 PPU Plug assembly PPU Plug assembly
41 4812157057 O-ring
42 Screw Screw
43 Set screw Set screw
44 4700909525 Seal nut
45 4700902996 Plastic cap, green
50 Loop flusing Loop flusing
51 4812158153 Seal kit,cpl
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
