Каталог запасных частей к технике: DYNAPAC CA610PD. Decals
4
5
5
6
6
7
8
9
9
13
15
17
18
19
20
20
20
20
21
22
23
23
25
26
27
27
28
28
31
31
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4700991658 | Decal FUEL | |
| 2 | 4700903423 | Safety label, Rotating engine components | |
| 3 | 4700903424 | Safety decal HOT SURFACE | |
| 4 | 4700903425 | Safety decal READ SAFETY INSTRUCTIONS | |
| 5 | 4700588176 | Decal LIFT POINT | |
| 6 | 4700904870 | Lifting data plate | |
| 7 | 4700624005 | Blind rivet 3,2x6,1 | |
| 8 | 4700903422 | Safety decal CRUSH AREA | |
| 9 | 4700903459 | Decal SAFETY | |
| 10 | 4700373364 | Slip protection | |
| 11 | 4700373363 | Slip protection | |
| 12 | 4700272372 | Decal HYDRAULIC OIL | |
| 13 | 4700272373 | Decal HYDRAULIC LEVEL | |
| 14 | 4700377742 | Reflector, red | |
| 15 | 4700377744 | Reflector, yellow | |
| 16 | 4700377743 | Reflector, white | |
| 17 | 4700384159 | Instructions Loading-Unloading | |
| 18 | 4700904835 | Decal BATTERY POWER | |
| 19 | 4700908229 | Safety decal | |
| 20 | 4700382751 | Decal SECURING POINT/TIE DOWN | |
| 21 | Warning plate | Warning plate, don't leave platform | |
| 22 | 4700624017 | Blind rivet | |
| 23 | 4700903985 | Decal SAFETY | |
| 24 | 4700388449 | Decal ENGINE COOLANT FILL | |
| 25 | 4812265828 | Decal Dynapac | |
| 26 | 4812265827 | Decal Dynapac | |
| 27 | 4700390900 | Decal TYRE PRESSURE | |
| 28 | 4812269831 | Decal AC H=140 | |
| 29 | 4812265836 | Cab decal | |
| 30 | 4812265837 | Cab decal | |
| 31 | 4812265838 | Cab decal | |
| 33 | 4812120119 | Decal Atlas Copco Black | |
| 34 | 4812269858 | Decal Atlas Copco Black, H=250 | |
| 35 | 4812269829 | Decal AC H=45 |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
