1
2
3
4
5
6
7
8
9
10
11
12
13
13
14
14
15
16
17
Позиция на иллюстрации
Заводской номер детали
Название детали
1
Coolerstandmodule
Cooler stand module
2
Hoseassykit
Hose assy kit
3
4812122685
Water cooler
4
4700162004
Sealing
5
4700792322
Hose connection
6
4812114280
Shock absorber
7
4812121866
Hydraulic oil cooler
8
4812112097
Shock absorber
9
4812121815
Charge air cooler
10
4812112097
Shock absorber
11
4812129494
Charge air hose
12
4812129563
Charge air hose
13
4812126568
Clamp
14
4812126236
Clamp
15
4812126432
Insulation
16
4812129373
Spring
17
4812115837
Cable tie
