1A
4700945622
4700945660
4700945661
2A
3A
4A
5A
7A
1B
4700909535
4700909536
4700936283
4700372696
4700372697
2B
2B
4B
5B
5B
7B
7B
8B
Позиция на иллюстрации
Заводской номер детали
Название детали
1A
4700377518
Drivers seat, cpl
4700945622
4700945622
Seat switch
4700945660
4700945660
Seat cushion, kit
4700945661
4700945661
Adjuster kit
2A
4700390561
Seat frame
3A
4700390963
Arm rest kit
4A
4700902286
Lock nut
5A
4700904229
Washer
7A
4700500053
Hex. screw
1B
4700370234
Seat, galon suspensioned
4700909535
4700909535
Sliding rail with handle
4700909536
4700909536
Sliding rail
4700936283
4700936283
Seat switch
4700372696
4700372696
Arm rest, left
4700372697
4700372697
Arm rest, right
2B
4812126698
Seat frame
4B
4700902286
Lock nut
5B
4700904556
Steel plain washer
7B
4700500053
Hex. screw
8B
4700508025
Bolt
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
