1
1
1
2
3
4
5
5
6
7
8
9
9
10
10
Позиция на иллюстрации
Заводской номер детали
Название детали
1
4812119364
Cab, cpl Comfort
1
4812119365
Cab, cpl Basic
1
4812124074
Cab, cpl Basic manual ac
2
ManualBox
Manual Box
3
4700904233
Steel plain washer
4
4700903290
Steel plain washer
5
4700947705
Hexagon head screw
6
4812115387
Protective plug
7
4812129972
Shock absorber
8
4812125174
Shock absorber
9
4700904703
Plain washer
10
4700947688
Screw
