Каталог запасных частей к технике: DYNAPAC CA4000D. Front section

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
2
3
4
5
6
7
8
9
9
10
10
11
11
12
13
14
15
16
17
18
19
20
21
22
22
23
23
24
25
26
27
28
29
30
31
32
32
32
33
33
33
34
35
36
37
37
38
39
40
41
42
Позиция на иллюстрации Заводской номер детали Название детали
1 Servopistoncover Servo piston cover
2 Screw Screw
3 4812157065 O-ring
4 Screw Screw
5 4812158266 Servo piston assy
6 O-ring O-ring
7 Pistonring Piston ring
8 4812157060 Spool
9 4812157061 Spring
10 Plug Plug connector see engine Gr. 9
11 O-ring O-ring
12 4812157062 Loop flushing relief valve
13 4812157063 O-ring
14 Endcap End cap
15 Servopiston Servo piston
16 Springguide Spring guide
17 Spring Spring
18 Settinglug Setting lug
19 Settinglugpin Setting lug pin
20 Setscrew Set screw
21 Buttonheadscrew Button head screw
22 Plug Plug connector see engine Gr. 9
23 O-ring O-ring
24 Screw Screw
25 Plug Plug connector see engine Gr. 9
26 O-ring O-ring
27 4812158265 Valve segment assembly
28 Controlhousing Control housing
29 4812156999 Shuttle valve assembly
30 Plug Plug connector see engine Gr. 9
31 O-ring O-ring
32 Plug Plug connector see engine Gr. 9
33 O-ring O-ring
34 4812157070 Spool
35 Screw Screw
36 4812157080 Control seal
37 Orificeplug Orifice plug
38 4812157071 Solenoid proportional valve
39 4812157072 Coil kit
40 4812157371 O-ring
41 Plasticcap Plastic cap
42 Screw Screw
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
