Позиция на иллюстрации
Заводской номер детали
Название детали
4812117550
4812117550
Bolt on pad shell kit
1
4812114382
Pad shell
2
4700500207
Hexagon head screw
3
4700586022
Lock nut
4
4700904233
Steel plain washer
5
4700500286
Screw
7
4700382572
Mounting screw
8
4700570015
Lock nut
9
4700382571
Hexagon sleeve
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
