Каталог запасных частей к технике: DYNAPAC CA3500D. Exhaust system
1
2
3
4
4
4
4
5
5
6
7
8
9
10
11
12
13
14
15
16
17
18
18
19
19
20
21
21
22
22
23
24
25
26
27
27
27
27
27
27
27
28
28
29
29
30
31
32
33
33
34
35
36
37
38
38
39
39
40
41
42
50
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 1 | 4812123815 | Bracket | |
| 2 | 4812123816 | Bracket | |
| 3 | 4812123820 | Bracket | |
| 4 | 4700904557 | Washer | |
| 5 | 4700500029 | Hex. screw | |
| 6 | 4812123821 | Clamp | |
| 7 | 4812123600 | Diesel Oxidation Catalyst | |
| 8 | 4700904228 | Steel plain washer | |
| 9 | 4700500015 | Hex. screw | |
| 10 | 4812122624 | Bracket | |
| 11 | 4700500033 | Screw | |
| 12 | 4812122027 | Clamp | |
| 13 | 4812124317 | Catalytic converter | |
| 14 | 4812122028 | Bend | |
| 15 | 4812122942 | Mixing pipe | |
| 16 | 4700904229 | Washer | |
| 17 | 4700500019 | Hex. screw | |
| 18 | 4812121795 | V-band clamp | |
| 19 | 4812121797 | Gasket | |
| 20 | 4812123819 | Exhaust pipe | |
| 21 | 4812121796 | V-band clamp | |
| 22 | 4812121798 | Gasket | |
| 23 | 4812123822 | Bracket | |
| 24 | 4700500028 | Screw | |
| 25 | 4700923269 | Clamp | |
| 26 | 4700570005 | Hex. nut | |
| 27 | 4700904556 | Steel plain washer | |
| 28 | 4700904241 | Screw | |
| 29 | 4700792441 | Cable tie with holder | |
| 30 | 4812118499 | Bracket | |
| 31 | 4812122030 | Exhaust pipe | |
| 32 | 4812122104 | Clamp | |
| 33 | 4811000481 | Pipe clamp | |
| 34 | 4812123818 | Exhaust pipe | |
| 35 | 4812123817 | Exhaust pipe | |
| 36 | 4812120857 | Gasket | |
| 37 | 4812120858 | V-band clamp | |
| 38 | 4700904231 | Washer | |
| 39 | 4700500056 | Screw | |
| 40 | 4811000481 | Pipe clamp | |
| 41 | 4812124003 | Holder | |
| 42 | 4700500053 | Hex. screw | |
| 50 | Delivered | Delivered with engine |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
