Позиция на иллюстрации
Заводской номер детали
Название детали
1
4812121866
Hydraulic oil cooler
2
4812112097
Shock absorber
3
4812121815
Charge air cooler
4
4812112097
Shock absorber
5
4812122151
Charge air hose
6
4812122152
Charge air hose
7
4700392810
Clamp
8
4700386966
Hose clamp
9
4700386966
Hose clamp
10
4812123010
Holder
11
4812118128
Clamp
12
4812117602
Strip
13
4700792119
Hexagon screw with flange
14
Coolerstandmodule
Cooler stand module
15
Watercooler
Water cooler
