Позиция на иллюстрации
Заводской номер детали
Название детали
1
Sideplate
Side plate
2
Sideplate
Side plate
3
4700903290
Steel plain washer
4
4700500284
Screw
5
4700927411
Screw
6
4700925208
Screw
6A
4700925208
Screw
7
4812112159
Ballast weight
8
4700500287
Screw
9
4812114179
Cross beam
10
4700904233
Steel plain washer
10A
4700904233
Steel plain washer
11
4812121294
Crossbeam
12
4812112162
Cover
13
4700904228
Steel plain washer
14
4700232041
Filter plug
15
4700500013
Hex. screw
17A
4812117507
Steering hitch, cpl
17B
Steeringhitch
Steering hitch
18
4700904230
Washer
19
4700500028
Screw
20
4812113607
Bracket
21
4700500028
Screw
22
4812113885
Protective hood
23
4700902166
Edge trim
24
4700500161
Screw
25
4700377742
Reflector, red
27
4700791396
Protective plug
28
4700377743
Reflector, white
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
Дополнительная информация
×
Название:
Номер:
Примечание:
