Каталог запасных частей к технике: DYNAPAC CA250D. Vibration system
1
2
3
3
5
7
7
8
8
9
9
9
10
10
11
11
12
13
13
14
14
15
15
16
17
18
18
19
19
20
21
22
23
24
25
27
28
28
29
30
31
33
34
35
35
36
37
38
| Позиция на иллюстрации | Заводской номер детали | Название детали | |
|---|---|---|---|
| 4700160234 | 4700160234 | O-ring | |
| 4700355634 | 4700355634 | Splined sleeve | |
| 1 | 4700395384 | Vibration pump | |
| 2 | 4700395386 | Hydraulic motor, vibration | |
| 3 | 4700334138 | Adapter | |
| 5 | 4700334205 | Straight connector | |
| 7 | 4700929226 | Flange half | |
| 8 | 4700904773 | O-ring | |
| 9 | 4700904230 | Washer | |
| 10 | 4700500030 | Hexagon head screw | |
| 11 | 4700900229 | Measuring fitting | |
| 12 | 4700483286 | Hydraulic hose | |
| 13 | 4700484235 | Hydraulic hose | |
| 14 | 4700484234 | Hydraulic hose | |
| 15 | 4700483031 | Hydraulic hose | |
| 16 | 4700482391 | Hydraulic hose | |
| 17 | 4700483999 | Hydraulic hose | |
| 18 | 4700373016 | Hose clamp | |
| 19 | 4700500028 | Screw | |
| 20 | 4700373423 | Spacer | |
| 21 | 4700373270 | Hose clamp | |
| 22 | 4700500033 | Screw | |
| 23 | 4700900512 | O-ring | |
| 24 | 4700904231 | Washer | |
| 25 | 4700502059 | Screw | |
| 27 | 4700791819 | Flange fitting | |
| 28 | 4700791823 | Adapter | |
| 29 | 4700334134 | Connector | |
| 30 | 4700234119 | Adapter | |
| 31 | 4700904586 | Elbow | |
| 33 | 4700904703 | Plain washer | |
| 34 | 4700947688 | Screw | |
| 35 | 4700813499 | Elbow | |
| 36 | 4700904584 | Connector elbow 90 ORFS | |
| 37 | 4700160279 | O-ring 70 | |
| 38 | 4700904637 | Washer |
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
