Каталог запасных частей к технике: DYNAPAC CA2500D. Port plate with valves

zoom-in zoom-out enlarge shrink circle-right circle-left file-text2 info cart
1
1
1
2
3
4
5
6
7
8
9
10
11
12
13
20
20
21
22
30
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
47
47
47
47
47
48
49
50
51
52
53
Позиция на иллюстрации Заводской номер детали Название детали
1 4812157796 Pressure relief valve
2 Locking screw Locking screw
3 Valve collar Valve collar
4 Valve spindle Valve spindle
5 Spring loading nut Spring loading nut
6 Pressure spring Pressure spring
7 Spring, cone-shaped Spring, cone-shaped
8 Threaded pin Threaded pin
9 Adjustment bolt Adjustment bolt
10 4700927278 O-ring
11 O-ring O-ring
12 Sealing nut Sealing nut
13 4812157799 Back-up ring
20 4812158770 Locking set with orifice
21 Locking screw Locking screw
22 4700927278 O-ring
30 4812157861 Pressure overide valve
31 Locking screw Locking screw
32 Valve bushing Valve bushing
33 Control piston Control piston
34 Piston Piston
35 Valve piston Valve piston
36 Poppet seat Poppet seat
37 Pressure spring Pressure spring
38 Spring collar Spring collar
39 Adjusting screw Adjusting screw
40 4700902783 O-ring
41 Sealing nut Sealing nut
42 4812157097 O-ring
43 Port plate Port plate
44 Socket head screw Socket head screw
45 Cylinder pin Cylinder pin
46 4812158776 O-ring
47 Double break-off plug Double break-off plug
48 Locking screw Locking screw
49 4812157151 O-ring
50 Locking screw Locking screw
51 Bush Bush
52 Bearing bushing Bearing bushing
53 4812158251 O-ring
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
