Позиция на иллюстрации
Заводской номер детали
Название детали
1
4812112182
Hydraulic pump, steering
2
4700904231
Washer
3
4700500046
Hex. head screw
4
4700791230
Adapter
5
4812113633
Flange connector
6
4700904774
O-ring
7
4700508048
Hexagon socket head cap screw
8
4812116589
Hydraulic block
9
4700904005
O-ring
10
4700904637
Washer
11
4700500090
Screw
12
4812114189
Adapter
