Позиция на иллюстрации
Заводской номер детали
Название детали
1
4812121128
Diesel engine
1
4812121129
Diesel engine
2
4700950302
Fuel filter element
3
4812156768
Fuel filter head
4
4700939068
Oil filter
5
4700950640
Alternator
6
4700950636
Starter
7
4812155851
Pre-fuel, cpl
7.1
4700950301
Pre-fuel filter element
7.2
4812160261
Separator bowl w. sensor
8
4700939070
Gasket, valve cover
9
4700950315
V-belt
10
4812159852
Oil dipstick
12
4812159853
Valve cover sealing
13
4812157954
Water pump
14
4812159599
Turbo charger
