1
2
3
4
5
6
7
8
9
10
11
12
Позиция на иллюстрации
Заводской номер детали
Название детали
1
4812117367
Bracket
2
4812117368
Bracket
3
4700396036
Compressor
4
4700904556
Steel plain washer
5
4700500021
Hex. screw
6
4700281327
Belt
7
4700395192
V-belt pulley
8
4700904230
Washer
9
4700792797
Hexagon socket head cap screw m
10
4700570103
Nut
11
4700791082
Screw
12
4700570006
Hex. nut
Содержащиеся в справочниках-каталогах запасные части и детали не предлагаются к продаже, а носят исключительно информационный характер
